Warehouse Automatic Industrial Overhead lifting Overhead Section
Galvanized Steel Thermal Insulation Sectional Door
The Industrial overhead lifting door adopts segmental-type door
plate to run the opening track suitable for the door, the balance
system balances the weight of the door body, the opening and
closing is light, low noise, high strength, and has the complete
sealing structure and performance. The door can be fully opened
without occupying the space in the room. The window can provide
customers with good lighting and transparency. With various
accessories and optional performance, the door can meet the
customers' requirements of firm, fast and space-saving industrial
building exterior wall.
Features:
1.It can be operated both automatically and manually according to
customer's actual demand.
2.The door is made of Polyurethane in the centre and zinc-plated
steel plate on two surface,grooved and embossed as well.
3. Transparent Window can be added to let light enter in and to
maintain temperature.
4.There are rubber seal stripes around all edges to prevent the
penetration of air and rainwater and transmission of warmth.
5.Life cycle:above 7000cycles.After some adjustment for the torsion
spring, life cycle can be doubled.
6.Integrated additional small door in the center is optional
according to request.
7. Intensifying ribs made of square steel bar will be added each
door panel for any door of more than 5 m in width .
8.Can be vertical lifting or turn lifting according to customer's
ceiling height.
Safety measures:
1.pinch-proof design
2. hanging steel rope on the top to prevent unwanted door dropping
3.safety airbag on the bottom
4.anti-breaking facility for the torsional spring
Warranty:
2 years warranty for door and 1 year warranty for motor. Some door panel and hinges will be sent with the shipment free of
charge according to the order quantity.
Product Description:
| Door panels | Panle style | Finger protection/general type |
| Panel construction | Steel+PU Foam+Steel |
| Panel thickness | 40/50mm |
| Panel max height | 575mm |
| Panle color | White,grey,walnut,mahogany,cream,OEM |
| Panel surface texture | Orang or Wood finished |
| Panel type | Flat,Stripe,block |
| Panel steel thickness | 0.376mm/0.476mm |
| Door Hardwares | Track style | Double track/ Single track |
| Track Thickness | 2.0mm |
| Track Cover | Available |
| Track&Track cover surface finished | Bright Zinc Galvanized |
| Hinges&Roller Brackets thickness | 2.0mm |
| Bearing Bracket thickness | 2.5mm |
| Top &Bottom Stretch | Plastic or Aluminum |
| Top&Side&Bottom Rubber | Included |
| Safety system | | Available |
| Spring break safety brackets |
| available |
| Cable break Safety system |
| Door Motor | Motor Voltage | 110V or 220V |
| Motor Force | 600N/800N/100N/1200N |
| Motor lift Height | 2.2m/2.5m/2.8m/3.1m/3.4m |
| Motor Remote Controls | 2 or more |
| Motor sensor/Alarming/Wall Brackets/ | Available |
| Keypad/Back battery |
|
Why Choose Us?
Customers satisfaction is our eternal goal. We adhere to the management principles of "quality first, customer
first and credit-based" since the establishment of the company and
always do our best to satisfy potential needs of our customers. Our company is sincerely willing to cooperate with enterprises from
all over the world in order to realize a win-win situation since
the trend of economic globalization has developed with
anirresistible force.
Over the years, our company has been working with the well-known
manufacturers work closely with gated, has introduced the latest
and most sophisticated production equipment of various volumes
gate. The use of superior Quality raw materials and high-quality
components, and adhere to the " excellence, precision production"
product concept, to ensure the production of a variety of beautiful
rolling door products Generous, easy operation, security, security,
durability, quality assurance. We spirit of "honesty, quality first, customer first, service
leader," the case Purpose, passion for the community to provide the
safest customers the best a variety of roll gates, but also provide
comprehensive maintenance service.
F A Q :
1,Are you trading company or manufacturer ?
A: We are factory.
2. What's the payment details?
Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T
in advance ,balance before shippment.
3. What's the delivery time?
For common order, about 15 days only.
4. What about the warranty for the doors?
We provide 12 months warranty for all doors and accessories.
5. Do you provide OEM Service?
Yes. OEM & ODM Service is ok for us.
6. What's the MOQ?
We accept 1 set as sample order.
7. How about the package?
Plywood case, suitable for sea freight or air freight, as your
request.
